Precision Hot Air station TESE
TESE is a precision hot air station capable of reworking small and medium SMDs. Connecting an external thermocouple provides a high-precise close-loop control of the component/PCB during the rework process or can also be used to protect a component or a specific area of the PCB. As all the JBC Stations, the TESE has a menu with more than 10 parameters to customize the control unit.
Technical data:
- Nominal power: 300W
- Selectable temperature: 150 to 450 °C / 300 to 840 °F
- Air flow regulation: 2 to 17 SLPM
- Vacuum: 30% / 228 mmHg / 9 inHg
- Profiles: 25 (up to 10 steps for each), 1 preset profile
- Type K TC connector: 1 for Control & Protection
- ESD safe: Meet ANSI / ESD S20.20-2021
- Equipotential bonding: Connection to EPA
- Pedal connector: Tool control
